GAME WITH CONFIDENCE. Must-have Zen 2 performance for every gamer. Easy on the wallet, tough on opponents.
BUILD WITH CONFIDENCE
Not only are these processors drop-in ready on AMD 500, 400 and select 300 series motherboards with a simple BIOS update, you can easily tweak and tune your processor with AMD Ryzen Master and AMD StoreMI.
AMD RYZEN TECHNOLOGIES
All AMD Ryzen 4000 Series processors come with the full suite of AMD Ryzen technologies designed to elevate your PC’s processing power including Precision Boost 2 and Precision Boost Overdrive.
AMD WRAITH STEALTH COOLER INCLUDED
AMD has upped the ante with the premium, low-profile Wraith Stealth cooler. This cooler features near-silent acoustics and capable thermal performance.
PRECISION BOOST 2
Precision Boost 2 automatically raises processor frequencies for supercharged performance, always watching temperature and power consumption to intelligently deliver high quality results for your PC.
AMD StoreMI
AMD StoreMI technology is the fast and easy way to expand and accelerate the storage in a desktop by combining the speed of an SSD with the capacity of an HDD.
AMD RYZEN MASTER
Use AMD Ryzen Master with your AMD Ryzen desktop processor to easily personalize performance.
Specifications
Platform
Desktop
Product Family
AMD Ryzen™ Processors
Product Line
AMD Ryzen™ 5 4000 G-Series Desktop Processors with Radeon™ Graphics
Former Codename
“Renoir”
Architecture
“Zen 2”
# of CPU Cores
6
Multithreading (SMT)
Yes
# of Threads
12
Max. Boost Clock
Up to 4.2GHz
Base Clock
3.7GHz
L1 Cache
384KB
L2 Cache
3MB
L3 Cache
8MB
Default TDP
65W
AMD Configurable TDP (cTDP)
45-65W
Processor Technology for CPU Cores
TSMC 7nm FinFET
Package Die Count
1
Unlocked for Overclocking
Yes
CPU Socket
AM4
Supporting Chipsets
X570
X470
X370
B550
B450
B350
A520
A320
CPU Boost Technology
Precision Boost 2
Instruction Set
x86-64
Supported Extensions
AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64
Max. Operating Temperature (Tjmax)
95°C
Launch Date
7/21/2020
OS Support
Windows 11 – 64-Bit Edition
Windows 10 – 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
USB Type-C® Support
Yes
Native USB 3.2 Gen 2 (10Gbps) Ports
4
Native USB 3.2 Gen 1 (5Gbps) Ports
0
Native USB 2.0 (480Mbps) Ports
0
Native SATA Ports
2
PCI Express® Version
PCIe® 3.0
Native PCIe® Lanes (Total/Usable)
24/20
NVMe Support
Boot, RAID0, RAID1, RAID10
System Memory Type
DDR4
Memory Channels
2
Max. Memory
128GB
System Memory Subtype
UDIMM
System Memory Specification
Up to 3200MHz
Max Memory Speed
2x1R – DDR4-3200
2x2R – DDR4-3200
4x1R – DDR4-2933
4x2R – DDR4-2667
ECC Support
No
Integrated Graphics
Yes
Graphics Model
Radeon™ Graphics
Graphics Core Count
7
Graphics Frequency
1900 MHz
USB Type-C® DisplayPort™ Alternate Mode
Yes
- Socket: AM4
- On-Chip Graphics: Yes
- Speed: 3.7GHz
- Core Quantity: 6
- Prefix: Ryzen 5
